Net weight: 15.5KG Total weight: 18KG

Product size (MM) : 324W×370D×531H

Package size (MM) : 405W×425D×608H

Features & Benefits:

1, two frequency 10 inch low frequency drive unit and 1.34 inches (Φ44mm)

2, directivity 70° x 100°, frequency can be controlled to 1.5KHZ

3. As long as the exported stomatal speaker is 20-30CM away from the wall, it can break out a strong low frequency with a particularly strong sense of encircling

4, the four-stage frequency divider design to ensure the reliable operation of the driver

5, sensitivity 96db(1M/1W), sound pressure level 120db

6, rated power 300W, peak 1200W

7. M8 multi-point hanging mode is convenient for hoisting

8, widely used in multi-function hall, all kinds of KTV places, teaching, auditorium, medium-sized conference rooms and other sound reinforcement places

Specifications & Parameters:

Speaker Type Two - frequency passive full - frequency speaker

Driver HF: 1.34 "×1 high-frequency drive unit

LF: 10 "×1 medium and low frequency drive unit

Frequency division point built-in two frequency division 2.4KHZ

Connect input 1 x NL4

Output 1 x NL4

Connection mode: ±1... LHF

Box type Trapezoidal box

Material 15mm medium fiber density board

Surface treatment box black polyimide spray

Face mesh black porous powder steel mesh and sound transmission speaker mesh cloth

Speaker power

Rated power RMS 300W

Continuous power 600W

Peak power 1200W

Directivity 70°×100° (H×V)

Sensitivity (1W/1M) 97db SPL

Sound pressure level: 123db SPL

Rated impedance (single) 8Ω

Electroacoustic index

Frequency response 60Hz-18KHz (±3db)

50Hz-20KHz (-10db)
